Bicycle Helmet Impact Sensors: Revolutionizing Rider Safety or Overrated Technology

Are bicycle helmet impact sensors truly effective in detecting concussions. How do these devices work and what are their limitations. Can impact sensors accurately measure the force experienced by a rider’s head during a crash. What do experts say about the reliability of helmet-mounted impact sensors. Is investing in an impact sensor for your bicycle helmet worth it.

The Rise of Bicycle Helmet Impact Sensors: A Closer Look

In recent years, the cycling world has seen a surge in the development and marketing of impact sensors designed to be attached to bicycle helmets. These devices, primarily accelerometers, aim to detect and measure the force of impacts during crashes or collisions. However, the effectiveness and reliability of these sensors have been subjects of debate among experts in the field of helmet safety and concussion research.

Impact sensors for helmets gained prominence around 2005 when they were first introduced for football players. Since then, numerous companies have entered the market, offering various devices claiming to enhance rider safety. But do these sensors live up to their promises? Let’s delve deeper into the world of bicycle helmet impact sensors to understand their potential benefits and limitations.

How Do Bicycle Helmet Impact Sensors Work?

Bicycle helmet impact sensors typically utilize accelerometers to measure the force of an impact. These devices are designed to be attached to the helmet’s exterior or integrated into its structure. When a significant impact occurs, the sensor registers the force and provides some form of alert or data readout.

Most commercially available sensors use one to three accelerometers to capture impact data. However, experts argue that this may not be sufficient for accurate measurements. To capture the full spectrum of forces involved in an impact, a minimum of seven accelerometers, oriented in different planes, would be necessary. For even greater accuracy, eleven accelerometers would be ideal.

Types of Impact Sensors

• Single-accelerometer devices
• Multi-accelerometer systems
• Helmet-mounted sensors
• Mouthguard-integrated sensors

While helmet-mounted sensors are the most common, some researchers have explored alternative placement options, such as mouthguard-integrated sensors. These aim to measure forces closer to the head itself, potentially providing more accurate data.

The Limitations of Helmet-Mounted Impact Sensors

Despite their popularity, helmet-mounted impact sensors face several significant limitations that call into question their effectiveness in accurately assessing the risk of concussion or head injury.

Measuring Helmet Impact vs. Head Impact

One of the primary concerns with helmet-mounted sensors is that they measure the force experienced by the helmet itself, not the force transmitted to the rider’s head. This discrepancy is crucial because the helmet’s primary function is to absorb and dissipate impact energy.

As a result, the force recorded by the sensor on the helmet’s exterior can be significantly higher than what the rider’s head actually experiences. This disparity can lead to false alarms or, more concerningly, a failure to detect potentially concussive impacts that may not register as severe on the helmet’s surface.

Limited Directional Sensitivity

Most commercially available impact sensors use only one or three accelerometers. This limited number of sensors can only measure forces in specific directions, potentially missing crucial data from impacts occurring at different angles.

To capture a comprehensive picture of an impact’s force and direction, experts recommend using a minimum of seven accelerometers oriented in various planes. Some researchers even suggest that eleven accelerometers would provide optimal accuracy.

The Complexity of Concussion Diagnosis

While impact sensors can provide valuable data on the forces involved in a crash or collision, it’s important to understand that they cannot diagnose concussions on their own. The relationship between impact force and concussion risk is complex and not fully understood by medical professionals.

Variability in Concussion Thresholds

Research has shown that there is no universal threshold for concussive impacts. Some athletes have experienced peak forces of 140 g’s without sustaining a clinically diagnosable injury, while others have suffered concussions from impacts below 80 g’s. This variability makes it challenging to establish definitive guidelines for concussion risk based solely on impact force measurements.

Multiple Factors Influencing Concussion Risk

The likelihood of sustaining a concussion depends on various factors beyond just the peak force of an impact. These include:

• Direction of the impact
• Area of impact on the head
• Rotational forces
• Individual physiology and susceptibility
• Previous history of concussions

Impact sensors, particularly those mounted on helmets, cannot account for all these factors, limiting their ability to accurately predict concussion risk.

Expert Opinions on Bicycle Helmet Impact Sensors

The scientific and medical communities have expressed mixed views on the effectiveness and reliability of bicycle helmet impact sensors. While some see potential benefits in certain applications, many experts urge caution in relying too heavily on these devices for concussion detection or helmet damage assessment.

FDA Warning

In April 2019, the U.S. Food and Drug Administration (FDA) issued a warning to the public regarding the use of medical devices marketed to consumers for assessing, diagnosing, or managing head injuries, including concussions and traumatic brain injuries (TBI). This warning underscores the limitations of current technology in accurately diagnosing concussions and highlights the importance of seeking professional medical evaluation following a head impact.

Research Perspectives

Researchers studying impact sensors, such as the Simbex HIT system used in football, have gathered extensive data on head impacts. However, they have found that correlating impact data with concussion occurrence remains challenging. While these systems can alert coaches to players experiencing numerous hard hits, they cannot definitively diagnose concussions or predict their likelihood based solely on impact force.

Potential Applications of Impact Sensors in Cycling

Despite their limitations, bicycle helmet impact sensors may still have valuable applications in certain contexts. Understanding these potential uses can help cyclists and teams make informed decisions about incorporating this technology into their safety protocols.

Tracking Cumulative Impact Exposure

One promising application of impact sensors is in tracking cumulative impact exposure over time. This data could be particularly useful for professional cyclists or those who frequently participate in high-risk cycling disciplines. By monitoring the number and intensity of impacts a rider experiences, coaches and medical professionals can better assess potential risks and adjust training or racing strategies accordingly.

Identifying High-Risk Behaviors

Impact sensors can help identify patterns of high-risk behavior or situations that lead to frequent impacts. This information can be used to develop targeted training programs or make course adjustments in racing scenarios to reduce the likelihood of crashes and collisions.

Research and Development

The data collected by impact sensors can contribute to ongoing research in helmet design and safety standards. By analyzing real-world impact data, manufacturers and researchers can work towards developing more effective protective gear and refining safety guidelines for cyclists.

Alternative Approaches to Assessing Helmet Damage

While impact sensors aim to provide objective data on crash forces, many experts still advocate for traditional methods of assessing helmet damage. These approaches focus on visual inspection and physical examination of the helmet following a crash or impact.

Visual Inspection Techniques

Experienced helmet technicians and safety experts recommend a thorough visual inspection of a helmet after any significant impact. This process involves carefully examining the helmet’s exterior and interior for signs of damage, such as:

• Cracks or deformations in the outer shell
• Compressed or crushed foam liner
• Separation between the shell and liner
• Damage to straps or retention systems

While this method requires some expertise to identify subtle signs of damage, it remains one of the most reliable ways to assess a helmet’s integrity after a crash.

Measuring Foam Crush

Another effective technique for evaluating helmet damage involves measuring the thickness of the foam liner at various points. By comparing these measurements to the original specifications, technicians can determine if the foam has been permanently compressed or damaged during an impact.

This method can reveal internal damage that may not be visible from the exterior, providing a more comprehensive assessment of the helmet’s protective capabilities.

The Future of Bicycle Helmet Safety Technology

As research in the field of head injury prevention continues to advance, we can expect to see further developments in bicycle helmet safety technology. While current impact sensors have limitations, ongoing studies and technological innovations may lead to more accurate and reliable systems in the future.

Integrated Sensor Networks

Future helmet designs may incorporate more comprehensive sensor networks, combining multiple types of sensors to provide a more holistic view of impact forces and head movement during a crash. These integrated systems could potentially overcome some of the limitations of current single-sensor designs.

Machine Learning and AI Applications

As more data is collected from impact sensors and clinical concussion research, machine learning algorithms and artificial intelligence could play a role in improving the accuracy of impact analysis. These technologies may help identify subtle patterns or combinations of factors that are more predictive of concussion risk than simple force measurements alone.

Personalized Risk Assessment

Advancements in biomedical research may eventually lead to more personalized approaches to concussion risk assessment. By combining impact sensor data with individual physiological factors and medical history, future systems could provide more accurate and tailored risk evaluations for each rider.

In conclusion, while bicycle helmet impact sensors represent an intriguing development in cycling safety technology, their current limitations and the complexity of concussion diagnosis necessitate a cautious approach to their use and interpretation. As research progresses and technology evolves, we may see more effective and reliable systems emerge. In the meantime, cyclists should continue to prioritize proper helmet fit, regular inspections, and prompt medical evaluation following any significant head impact.

Bicycle Helmet Impact Sensors

Impact Sensors for Helmets

Summary: Many brands of impact sensors are being sold to be added to helmets to detect hard impacts. They have limited usefulness for bicycle helmets, and limited accuracy at best. Most measure blows to the helmet, not the g’s the head inside experienced after the helmet’s energy management. The biggest risk is that they will fail to signal a concussive event or fail to signal damage to the helmet. Researchers believe they can signal hard impacts but can not diagnose concussions. They are primarily useful in multi-impact sports for tracking sub-concussive blows.

You should read this cautionary announcement from the FDA “warning the public not to use medical devices marketed to consumers that claim to help assess, diagnose or manage head injury, including concussion, traumatic brain injury (TBI) or mild TBI. “

Impact sensors (usually accelerometers) attached to football players’ heads made news about 2005, and devices to attach to helmets have been marketed by a number of companies since.

A sensor attached to a helmet can only record the g’s that the helmet sees, not what the head inside experienced. Since the helmet is managing the energy, there will be a huge difference, with the head seeing far less shock. The original Simbex HIT system for football players mounts an array of accelerometers against the player’s head, not on the outside shell of the helmet.

Accelerometers are linear, registering g’s in only one direction. To capture all of the energy in an impact, seven is the minimum number of accelerometers to use, oriented in different planes. Eleven would be more accurate. Most of the devices marketed now use only one accelerometer, or at most three.

The Simbex product uses multiple accelerometers held against the head, and gathers the data on the sidelines of a game through a wireless connection. It works, and can alert the coach when a player takes a very hard hit. Simbex and the college football researchers using the system have gathered millions of hits in their data collecting. But correlating the hits and concussions has proven elusive. There is still no agreement on the exact profile of a concussive hit. Some players have experienced 140 peak g’s without an injury that can be diagnosed clinically. Some have been concussed at levels below 80 g’s. Results vary depending on the direction of the blow, area of the impact and other factors. There is no precise way yet to define the characteristics of the hit that produces a concussion. Peak g has to be important, and rotational energy is believed to be another key element. Even a straight linear hit involves some rotational component. But what is happening inside the head as the brain moves, as different brain components with different densities and placement move in different ways, contributes to the nerve and blood vessel strain that is thought to be a big determinant of concussion. Simbex says their system is best used by coaches to identify players who are experiencing many hard hits and permit the coach to train that player to avoid them in the future.

Back in 2006 we bought some samples of a device called the Shok-SpotR and asked experts for an evaluation. The device is designed to be added to a hard shell helmet, and registers g’s above a certain level by turning a spot red. We got mixed feedback from the lab techs and other experts, who saw it as a device to register helmet damage, since it did not register g’s to the head. Some felt that even assuming it functioned correctly, the spot might not change in some crashes that would damage the helmet. Most believed that visual inspection and measuring for foam crush after a crash is the best way to determine if a helmet has been damaged. But since many consumers are not experienced in looking at damaged helmets and may not recognize damage under a shell, there may still be a place for this product if you wear a helmet with a rigid hard shell. Our samples were $25 plus shipping, from a supplier we found with Google.

As concern about concussions has grown in recent years other devices have come on the market, including Impact Alert, Shockbox, the Stabilizer First Alert (attaches to a hockey face mask) and many others. There are also sensors with electronics in a mouth guard. Those at least try to measure g’s to the head, not the helmet, but must assume that the jaw remains firmly clamped on the mouthguard through the impact sequence. We found all of those and more with this Google search. It will be more current than any list we post here would be. We know nothing of the effectiveness of any of the devices except the Simbex HIT system, a reliable indicator of hits on a sports field.

In April of 2019 the US Food and Drug Administration (FDA) issued a press release”warning the public not to use medical devices marketed to consumers that claim to help assess, diagnose or manage head injury, including concussion, traumatic brain injury (TBI) or mild TBI. ” The only devices the FDA has cleared must be used by a health care professional, and “there are currently no devices to aid in assessing concussion that should be used by consumers on their own.” That is expert advice that none of us should ignore.

This mid-2018 post on the web by child athlete advocate Brooke de Lench represents a good review of the sensor field, except that it does not distinguish between sensors mounted on a helmet and those mounted against the head. She does make the point well that the sensors are primarily useful in multi-impact sports for tracking sub-concussive blows, not for diagnosing a concussive impact.

In 2016 the F08.53 Helmet and Headgear subcommittee of ASTM began developing a standard for the performance of sensors used to track head impacts. CPSC chairs the task group. The task group will have a difficult job, and the development of the standard may take some time. There has not been much progress as of late-2020. But eventually you may be able to buy an impact device with confidence that it meets a performance standard.

Bottom line: many of the sensors are designed for use with hard shell helmets. Most will not tell you much about how hard an impact your brain actually took or whether an injury has occurred. We do not know of a consumer product that will tell you if you have a concussion, and for bike riders a medical diagnosis of the symptoms you are experiencing will always be your best indicator. If you are crashing repeatedly and need to track the number of hits your helmet experiences, there are products to do that.

Football helmet sensors monitor impact of collisions, tackles

The problem of concussions in football players arising from helmet-to-helmet collisions is receiving attention on a number of levels. According to an article in the Hendersonville Lightning, high schools in Hendersonville, North Carolina, are outfitting helmets with sensors that measure the G-force of hits on the field, in an effort to gauge the impact of collisions or tackles and flag possible concussions.

With donations from the Pardee Hospital Foundation, all four of the Hendersonville public high school football teams have helmets that a few athletes playing the more vulnerable positions will wear this season. According to the Hendersonville Lightning report, North Henderson has 12 sensor-equipped helmets and West Henderson, East Henderson and Hendersonville have four each.

“Our goal was to get 12 for each school,” Karen Yagerhofer, of the Pardee Foundation, was quoted as saying. The helmets cost $500 each, compared to $300 for regular helmets. Pardee Hospital Foundation raised $8,600 in its cornhole tournament and used the proceeds to buy helmets.

The dime-sized sensors are fitted within the helmets and measures the G-force of hits on the field. The program’s proponents hope this information can help warn of potentially damaging hits. According to the article, an objective cognition test is used to complement what can be a subjective opinion on whether the player has a concussion.

The program is connected to the leading research program in the country into football concussions. The program has been used by the NCAA and the NFL to establish concussion treatment policies.

Dwayne Durham, director of Pardee’s sports medicine program, said in the report that the helmets neither prevent nor diagnose a concussion, but they can be valuable in alerting athletic trainers to high-impact hits that could result in a concussion.

“We’re going to be using this for data collection because what it does is whenever a player receives a hit the athletic trainer will have this sensor that is actually programmed to that helmet and it will tell us how many G-forces. It doesn’t mean the kid has a concussion, but if it rings the buzzer, we’re going the stop kids from playing just to make sure they’re OK.”

Pardee added that any hit over 90 G-force can potentially cause injury to the brain leading to a concussion, and early detection is critical to better treatment.  “If they’re OK, we let ‘em go back,” he said. “If they’re not OK, they’re subject to a five-day treatment program.”

Jim Sosebee, the head football coach at Hendersonville High School, said in the report he’s glad the school will be able to test the extra protection. “If players take a big hit “we can check on them using the tracker that reads the G-force. I’m guessing some of the biggest hits will be when they hit the ground.”

RELATED:

Vibration meter measures frequencies to 4800 Hz

New Smart Helmet Could Spot Concussions in Real Time

David Butler II / USA TODAY Sports

This fall, tens of thousands of American football players, from grade-schoolers on up to the pros, will be treated for concussions. Experts suspect that for every player who is pulled from a game and diagnosed, another will have his or her injury go unnoticed, since only those who report feeling ill or display the most conspicuous signs of traumatic brain injury — such as losing consciousness or acting disoriented — are likely to be examined by a neurologist.

In order to detect concussions as they occur, and to help coaches determine quickly and conclusively when players should be taken off the field, a team of Columbia researchers is developing what would be the first wearable diagnostic device for traumatic brain injury. Called the NoMo, the device incorporates electroencephalography (EEG) sensors of the type commonly used in hospitals to measure a patient’s brain activity. The sensors, which would ordinarily be taped to the scalp, are instead tucked in between the pads of a football helmet. Upon detecting the distinct electromagnetic wave patterns of a traumatic brain injury, they will send an alert to a computer on the sidelines.

“Within seconds of a player being hit, everyone will know whether or not he’s suffered a concussion,” says James Noble ’08PH, a Columbia neurologist who designed the technology with Columbia biomedical engineer Barclay Morrison. “This will eliminate a lot of the problems you have now with coaches, athletic trainers, and team physicians having to make fairly subjective judgments about who should be removed from a game to receive a full neurological evaluation. ”

The idea for the NoMo was inspired by Noble’s experiences serving as a neurological consultant to collegiate and professional football teams. In that role, he helps the teams’ doctors determine if and when players who have been benched for concussions are fully recovered and battle-ready again. This is a critical decision, since a player who returns to the field and takes additional hits too soon after suffering a concussion is more likely to incur long-term neurological damage.

“Everybody involved in football wants a more reliable way of identifying when these injuries happen,” Noble says. “The culture of the game, at any level, is such that the players are often reluctant to volunteer that they’re hurt. Plus, the symptoms of a concussion can be subtle and hard to spot.”

Over the past decade, several other research teams have attempted to create wearable devices to detect concussions. Some have developed accelerometers that, when implanted in football helmets, measure the physical intensity of hits that players endure. The jostling of a player’s helmet has proved to be an imperfect proxy for concussions, though, and the NFL, after initially planning to use such devices in the 2016 season, ultimately shelved the idea.

EEG sensors inside a football helmet can detect concussions in real time. Photo courtesy of NoMo Diagnostics.

“One problem with accelerometers is that a concussion may result from an accumulation of hits rather than from one big one,” says Noble. “Our device is more reliable because it monitors the brain’s actual physiological activity in response to these hits. It will provide a real medical diagnosis.”

Noble and Morrison conducted a preliminary test of the NoMo at a Columbia football practice last year. They found that it successfully recorded the players’ brain waves, but that it must be made smaller to fit comfortably into a helmet. They are currently working on a new version of the device.

Eventually, they say, the NoMo could be adapted for use in a number of contact sports, including hockey, wrestling, lacrosse, and, if the sensors can be made small enough to slip into a headband, soccer and basketball. Furthermore, they say, the device could be inserted into military helmets to detect when soldiers suffer concussions, either from being knocked off their feet or from enduring the shock waves caused by explosions.

“The beauty of our design is that it doesn’t matter what causes the concussion,” says Morrison. “If you experience a traumatic brain injury, a red light will go off on a computer and tell someone you need help.”
