Create a helmet. Innovative Helmet Design: Revolutionizing Head Protection in Sports and Beyond

How does the new helmet design by UC Berkeley neurologist Robert Knight improve protection against brain injuries. What are the key features that make this helmet more effective than traditional designs. Why is rotational force a critical factor in preventing traumatic brain injuries.

The Genesis of a Groundbreaking Helmet Design

In the realm of sports and outdoor activities, helmets play a crucial role in safeguarding athletes and enthusiasts from potential head injuries. However, not all helmets on the market today offer comprehensive protection against the complex forces that can lead to traumatic brain injuries (TBI). Enter Dr. Robert Knight, a neurologist from UC Berkeley, who has developed an innovative helmet design that promises to revolutionize head protection across various fields.

With 40 years of experience as an academic researcher and medical doctor, Dr. Knight has witnessed firsthand the devastating effects of head injuries on individuals’ lives and careers. His personal experiences, combined with his professional expertise, led him to create a helmet that addresses the limitations of current designs.

Key Features of the Revolutionary Helmet Design

Dr. Knight’s helmet design incorporates two critical improvements over traditional models:

1. Enhanced padding to better absorb direct impacts
2. An innovative outer shell that rotates to dissipate twisting forces

These features work in tandem to provide superior protection against both linear and rotational forces, which are equally dangerous to the brain.

Why Rotational Forces Matter

While many people focus on concussions resulting from direct impacts, Dr. Knight emphasizes that rotational forces can be just as harmful, if not more so. These twisting motions can tear brain fibers, leading to severe damage. The innovative outer shell of the new helmet design specifically addresses this issue by allowing for controlled rotation upon impact.

BrainGuard: From Concept to Prototype

To bring his vision to life, Dr. Knight founded BrainGuard, a company dedicated to developing and promoting this new helmet technology. Over the past eight years, the BrainGuard team has produced prototype helmets for various sports and activities, including:

• Football
• Hockey
• Baseball
• Cycling
• Motorcycling
• Snow sports

The versatility of the design allows it to be adapted for multiple uses, potentially benefiting not only athletes but also police officers, soldiers, and construction workers.

Real-World Testing and Feedback

The promising nature of Dr. Knight’s helmet design has not gone unnoticed in the sports world. Tim Feaster, UC Berkeley’s head football equipment manager, has had the opportunity to examine and test the prototype. His reaction was overwhelmingly positive, describing the technology as “incredibly fascinating” and unlike anything he had seen before.

Feaster’s experience with the helmet extends beyond personal testing. He has also facilitated trials with Cal football players, who responded favorably to the new design. This real-world feedback from athletes and equipment professionals provides valuable insight into the helmet’s potential impact on the sports industry.

Balancing Safety and Aesthetics

One challenge in introducing new helmet designs is the balance between safety features and aesthetic appeal. Feaster noted that players often prioritize the look of a helmet over its protective capabilities. However, he expressed confidence in the BrainGuard design, stating that he would “absolutely” offer it to his team once it receives proper certification.

The Global Impact of Traumatic Brain Injuries

Dr. Knight’s motivation for developing this innovative helmet design stems from the alarming statistics surrounding traumatic brain injuries. According to the Centers for Disease Control and Prevention, in 2014 alone:

• 2.9 million Americans were affected by TBI
• 288,000 TBI-related hospitalizations occurred
• 57,000 deaths were attributed to TBI

Even more concerning is the World Health Organization’s projection that TBI will become the leading cause of death and disability worldwide in the near future. These statistics underscore the urgent need for improved protective equipment across various sectors.

Expanding Beyond Sports: Potential Applications

While the initial focus of BrainGuard has been on sports helmets, the technology’s potential extends far beyond the athletic field. The company is actively developing prototypes for various industries and activities, including:

• Military applications
• Firefighting equipment
• Construction safety gear

This broader approach reflects Dr. Knight’s vision of improving quality of life by reducing the incidence and severity of traumatic brain injuries across all sectors of society.

The Science Behind Brain Protection

To fully appreciate the significance of Dr. Knight’s helmet design, it’s essential to understand the mechanisms of brain injury. When the head experiences a sudden impact or rotation, the brain can collide with the inside of the skull or undergo shearing forces that damage its delicate structures.

Linear vs. Rotational Forces

Traditional helmets have primarily focused on protecting against linear forces – direct impacts that can cause concussions. However, rotational forces, which cause the brain to twist within the skull, can be equally if not more damaging. These forces can lead to tearing of brain fibers and diffuse axonal injury, a severe form of brain trauma.

Dr. Knight’s design addresses both types of forces:

• The enhanced padding absorbs linear impacts
• The rotating outer shell mitigates rotational forces

The Vulnerability of Young Athletes

One crucial aspect of Dr. Knight’s research is the recognition that young athletes, particularly those in high school, are especially vulnerable to rotational injuries. Unlike professional athletes who may have developed stronger neck muscles, adolescents lack this natural protection against twisting forces.

This understanding has informed the design process, ensuring that the helmet provides adequate protection for athletes of all ages and skill levels.

Challenges in Helmet Adoption and Certification

Despite the promising nature of Dr. Knight’s helmet design, several challenges must be overcome before it can be widely adopted:

1. Certification: The helmet must meet rigorous safety standards set by various governing bodies.
2. Manufacturing scalability: Producing the helmet on a large scale while maintaining quality and affordability.
3. Athlete and team acceptance: Overcoming resistance to change and aesthetic preferences.
4. Education: Informing athletes, coaches, and parents about the importance of advanced protection against rotational forces.

Addressing these challenges will be crucial for BrainGuard as they move forward with commercialization efforts.

The Future of Head Protection Technology

Dr. Knight’s innovative helmet design represents a significant step forward in the field of head protection. As research continues and technology advances, we can expect to see further developments in this area. Some potential future directions include:

• Integration of smart sensors to detect and record impact forces
• Customizable helmet designs tailored to individual head shapes and sport-specific needs
• Development of even lighter and more durable materials for helmet construction
• Incorporation of augmented reality displays for enhanced situational awareness

These advancements could further revolutionize not only sports safety but also protective equipment in various high-risk professions.

Collaborative Research and Development

The success of Dr. Knight’s helmet design highlights the importance of collaboration between neuroscientists, engineers, and sports professionals. As research in this field progresses, we can expect to see more interdisciplinary approaches to solving the complex problem of traumatic brain injuries.

Universities, sports organizations, and private companies may increasingly partner to develop and test new protective technologies. This collaborative approach could accelerate innovation and lead to more rapid improvements in head protection across various industries.

The Broader Impact on Public Health

While the initial focus of Dr. Knight’s work has been on sports-related head injuries, the potential impact of this technology extends far beyond the athletic field. Improved helmet designs could have significant implications for public health, including:

• Reduction in healthcare costs associated with treating TBI
• Decreased long-term disability rates from head injuries
• Improved safety in high-risk occupations such as construction and emergency services
• Enhanced protection for recreational activities like cycling and skateboarding

By addressing the global challenge of traumatic brain injuries, innovations like Dr. Knight’s helmet design have the potential to save lives and improve quality of life for millions of people worldwide.

Changing Attitudes Towards Head Protection

As awareness of the dangers of TBI grows and new technologies emerge, we may see a shift in cultural attitudes towards head protection. Sports leagues, schools, and workplaces may implement stricter safety protocols and require the use of advanced protective equipment.

This cultural shift could lead to a greater emphasis on prevention rather than treatment, potentially reducing the incidence of TBI and its associated long-term consequences.

Economic Implications of Advanced Helmet Technology

The development and adoption of innovative helmet designs like Dr. Knight’s could have significant economic implications:

1. Market disruption: Established helmet manufacturers may need to adapt or risk losing market share to new, technologically advanced competitors.
2. Job creation: The growth of companies like BrainGuard could lead to new employment opportunities in research, engineering, and manufacturing.
3. Insurance industry impact: Improved head protection may lead to changes in insurance policies and premiums for high-risk activities and professions.
4. Healthcare savings: Reduction in TBI incidence could result in substantial savings for healthcare systems and individuals.

These economic factors may play a crucial role in driving further innovation and adoption of advanced helmet technologies.

Potential for Technology Transfer

The principles behind Dr. Knight’s helmet design could potentially be applied to other areas of safety equipment and protective gear. For example:

• Automotive safety: Incorporating similar rotational absorption technology into car headrests or airbags
• Fall protection: Developing advanced hardhats for construction and industrial workers
• Personal protective equipment: Enhancing body armor for law enforcement and military personnel

This potential for technology transfer could lead to a wave of innovation across multiple industries, further amplifying the impact of Dr. Knight’s initial research.

Ethical Considerations in Helmet Design and Usage

As advanced helmet technologies like Dr. Knight’s design become more prevalent, several ethical considerations arise:

1. Accessibility: Ensuring that these potentially life-saving technologies are available to all, not just elite athletes or those who can afford them
2. Mandatory usage: Determining whether the use of advanced helmets should be required in certain sports or professions
3. Data privacy: Addressing concerns about the collection and use of impact data if sensors are incorporated into helmet designs
4. Risk perception: Balancing improved protection with the potential for increased risk-taking behavior due to a false sense of invincibility

Addressing these ethical concerns will be crucial as the technology continues to develop and gain wider adoption.

The Role of Education and Awareness

Alongside technological advancements, education and awareness campaigns will play a vital role in reducing the incidence of traumatic brain injuries. Key aspects of these efforts may include:

• Educating athletes, coaches, and parents about the importance of proper helmet use and fit
• Raising awareness about the dangers of rotational forces and the benefits of advanced helmet designs
• Promoting a culture of safety in sports and other high-risk activities
• Providing training on recognizing and responding to potential head injuries

By combining technological innovation with comprehensive education programs, we can work towards a future where traumatic brain injuries are significantly reduced across all sectors of society.

New helmet design can deal with sports’ twists and turns

Helmets are essential for athletes and outdoor adrenaline junkies, but not all helmets on the market today provide good protection. UC Berkeley neurologist Robert Knight came up with an improved design that will help protect all helmet-wearers from forces that twist and snap the head and could damage the brain. (UC Berkeley video by Roxanne Makasdjian and Stephen McNally)

As a neurologist, Robert Knight has seen what happens when the brain crashes around violently inside the skull. And he’s aware of the often tragic consequences.

Throughout his 40 years as an academic researcher and medical doctor, the University of California, Berkeley, professor of psychology and neuroscience has known students and friends whose lives and careers were derailed by head injuries from bicycle and car crashes. He’s held in his hands brains destroyed by accidental blows to the head.

Not surprisingly, he cringes when he imagines his young grandchildren falling off a bike and hitting their heads.

So, Knight invented a better helmet — one with more effective padding to dampen the effects of a direct hit, but more importantly, an innovative outer shell that rotates to absorb twisting forces that today’s helmets don’t protect against.

His design is flexible enough to provide protection for football and hockey players — who receive the most severe and most frequent blows to the head — as well as police, soldiers, snowboarders and anyone who wears a helmet or hard hat. And yes, cyclists, too.

Most people think that a concussion — a bruise to the brain — is the most dangerous type of trauma, but a twisting motion is just as bad, because it can tear brain fibers. While beefy linemen develop strong necks that can withstand a limited amount of torque, children and adolescents — including most high school football players — do not.

“A direct linear impact to the head certainly is not good, but in addition, there are rotational forces that twist the brain. It’s like in boxing, where one roundhouse punch comes in, the head turns, and they are out,” Knight said. “That’s because the brain is just not designed to take rotation; you end up with damage to critical connecting fibers in the brain.”

BrainGuard

Eight years ago, he founded a company, BrainGuard, to develop the new helmet design and attract interest from major helmet manufacturers. So far, he and his four-person team have produced prototype football, hockey, baseball, bike, motorcycle, sports utility and snow-sport helmets.

BrainGuard’s line includes improved helmets for baseball, cycling and hockey in addition to football. The company is developing prototypes for all sports as well as military, firefighting and construction. All incorporate a rotational shock absorber to reduce damage from torques to the head. (Photos courtesy of Robert Knight)

“Because I am a neurologist, I would like to see something out there that improves the quality of life of people by diminishing traumatic brain injury and its resultant effects on the brain and emotional and cognitive and behavioral function,” said Knight, former head of UC Berkeley’s Helen Wills Neuroscience Institute. “That is my hope.”

UC Berkeley’s head football equipment manager, Tim Feaster, first tried on the helmet a year ago, when he was assistant equipment manager with the Oakland Raiders, and subsequently helped Knight get it onto the heads of a couple of Cal players, who liked it, Feaster said.

“I think the technology is incredibly fascinating,” he said, adding that he would “absolutely” offer the football helmet to his team once it’s certified. “I have never seen anything like it: an outer shell that moves over the inner shell was intriguing to me. It was so inventive, it made sense the way it moved. I thought they might actually have something here.”

Feaster admitted that a player’s choice of helmet — currently Cal football players can select from more than 15 styles from four manufacturers — is often more about esthetics than safety. And concussion is the main concern.

“But I am all for getting guys to at least try it, if I believe in it,” he said. “Any way that a new technology can at least limit the damage, I am all for it.”

TBI, world’s leading cause of death and disability

Knight quotes startling figures on the extent of traumatic brain injury (TBI) in the United States. The Centers for Disease Control and Prevention tracked 2.9 million Americans affected by TBI in 2014, primarily from falls and motor vehicle crashes. While most of the injuries were mild concussions, the total included 288,000 hospitalizations and 57,000 deaths. The World Health Organization estimates that TBI will be the leading cause of death and disability in the world this year.

Robert Knight, who normally studies basic brain functions like memory and treats patients with Alzheimer’s and Parkinson’s disease, invented a new type of helmet in order to prevent brain injury from head trauma. (UC Berkeley photo by Stephen McNally)

Yet, these figures don’t account for many sports-related concussions that don’t result in an ER visit but force a player to sit out the rest of the game. The Brain Injury Research Institute estimates there were 135,000 sports-related concussions in individuals ages 5 to 18 between 2001 and 2005. While concussion symptoms — headache, nausea, fatigue, confusion or memory problems, sleep disturbances and mood changes — typically go away, the cumulative effect of repeated mild concussions could be grave.

“Most people think that the inside of the skull is a nice smooth container, like an eggshell, holding the precious brain,” he said. ”It’s not true. The inside of the skull is filled with all kinds of bony ridges that can be quite destructive, similar to if I hit you in the arm, and you get a bruise. But if you bruise the brain, the blood kicks off a cascade of reactions that actually kill brain cells.”

When bruising happens again and again, even without a concussion, a person can get chronic traumatic encephalopathy (CTE), a condition that has sparked controversy over the past decade and was the subject of the 2015 movie Concussion that starred Will Smith.

Especially in football linemen, CTE has led to an epidemic of early dementia, mood alterations and even suicide among retired professional players. In one study of 202 former football players whose brains were donated after death, 3 of 14, or 21% of those who had played only in high school, showed evidence of CTE. Of those who played football in college, 48 of 53, or 91%, had CTE. Of NFL (National Football League) players, 110 of 111 had CTE.

“That is the big gorilla in the room for the NFL and the NHL (National Hockey League),” Knight said.

The brain of a person who died from a brain hemorrhage after head trauma. (Photo courtesy of Robert Knight)

Yet, while contusions and blood clots in the brain are a big problem, equally damaging are the tears that occur when brain fibers are wrenched and twisted.

“The brain operates by one cell sending on its connecting fiber through an axon to signal another cell,” he said. “When you get these complex twisting and rotational forces, you get compression, tension and shearing, and you can actually mechanically damage and tear your connecting fibers.

The best helmets today, including those used by the NFL, include padding that does a decent job absorbing energy from a direct head collision and preventing the full force of the hit from reaching the brain. But they don’t account for hits that snap and rotate the head. The outer shell of Knight’s football helmet is able to rotate about an inch relative to the inside shell, which is strapped to the head; this absorbs the dangerous torque that can cause permanent brain damage. More spherical helmets, like those for bikes and snowboarders, could rotate about an inch and a half, absorbing even more rotational energy, he said.

To allow this helmet rotation, Knight places compact plastic struts between the inner and outer shell. The struts allow the outer shell to slide relative to the inner shell strapped to the head — essentially a rotational shock absorber.

Retrofitting today’s helmets

Knight and BrainGuard CTO Ram Gurumoorthy, who has a Berkeley Ph.D. in engineering, say that their design adds no extra weight or thickness to a football helmet, and that many helmet models today could be retrofitted by adding the new outer shell and struts. The design, which also includes a lighter, carbon-fiber face mask, can be adapted to any sport or recreation: climbing, off-road and all-terrain sports, as well as baseball, lacrosse, rugby and water polo, one of the most dangerous sports for concussions. The same inner shell with an interchangeable outer shell also works for industrial helmets and for firefighter and military helmets.

Knight and his BrainGuard team built a state-of-the-art testing machine to see how their new helmet design withstands direct and glancing blows to the head. (UC Berkeley photo by Stephen McNally)

“The beauty of the helmet is that it is a modular platform, which means the innards — the inside attached to the head — remain the same or quite similar, and the outside shell alone can change, depending on the sport,” Knight said.

BrainGuard’s football helmet passed the mechanical performance requirements as specified in National Operating Committee on Standards for Athletic Equipment in November, a first step toward offering it to high school, college and professional teams. The company is now setting up a small manufacturing line to produce about 1,000 football helmets — enough to test the design with a few high school and college teams, once the manufactured helmet has been certified — and looking for investor money to pay for injection molds and manufacturing lines for bicycle, motorcycle and snow-sport helmets.

“I want to emphasize that the football helmets on the market today are effective. What we are trying to do is make them more effective,” Knight said.

One standard test of helmets it to drop a weight directly on the helmet to see how it absorbs the force of a direct impact. (UC Berkeley photo by Stephen McNally)

At their company’s garage in an industrial park in Point Richmond, California, Knight and Gurumoorthy have built a state-of-the-art helmet testing machine to compare BrainGuard with commercial helmets. Knight says that the new design is 25 to 50 percent better than any on the market, in terms of damping rotational forces. Their design is particularly effective for frontal hits that contribute to CTE, which starts in the frontal lobe, Knight said.

“Our helmet can reduce the rotational force by up to a half, but you don’t eliminate it. This is not a panacea; we are reducing the influence of blows to the head,” he said.

More effective means of reducing traumatic head injuries would be to ban tackle football for kids under age 13 — many play in the Pop Warner Little Scholars Inc. leagues — and to change the way older players use their heads during practice and play. Unless contact sports are banned, which is unlikely, a better helmet will at least reduce the number of concussions, the damage from repeated subconcussions and the chances of developing CTE.

Knight’s greatest fear is that better helmets would encourage more violent and dangerous behavior.

“I am most worried that if you put out a better force-reduction helmet, people are not going to pay attention to other things they should be doing to reduce force to their heads, like reducing or eliminating helmet-to-helmet contact,” he said. “My dream is that someday, my 8-year-old granddaughter is going to be wearing a bike helmet that is well designed, so the one time she falls off her bike, she is going to get a dramatic decrease in the chance of her getting a serious brain injury.”
